- Receiver: L1Type, C/A Code
- Display: pixel height * width 128 x 64 dot matrix
- Key: 3 function keys
- Range of use: This product only work under outdoor sky areas around elevation 15 no building cases to receive satellite signals!
- Location: 10m (Support the difference correction system area up to 2 meters)
- This compass is reliable and accurate. Durable, it is an essential navigation tool for all outdoor activities. It can be used in any conditions. It is shockproof, waterproof, damage-resistant and sand-proof, and can operate smoothly in any environment
Receiver: L1Type, C/A Code
Capture channel: 51
Tracking channel: 14
Maximum update frequency: 10 Hz
Display: pixel height * width 128 x 64 dot matrix
Size: 65mmx 52mmx 21mm
Weight: 39.6g (With the battery)
Memory: 512KB
Key: 3 function keys
Location: 10m (Support the difference correction system area up to 2 meters)
Speed: 0.1m/s
The initial positioning time:
Hot start: About 5 seconds
Warm start: About 40 seconds
Cold start: About 2 Minutes
Sensitivity:-161dBm tracking/ -157dBm re capture/ -148dBm capture
Data protocol: NMEA-0183 v3.01
The power supply voltage: 5 V / 3.7 V 390 Ma the built-in lithium battery
The time: approximately 6 hours
Power waste:
Capture: about 70 Ma
Continuous tracking: about 30 Ma
Storage temperature: -30C to 85C
Working temperature: -20C to 75C
Humidity: Up to 80% non-condensing
Range of use: This product only work under outdoor sky areas around elevation 15 no building cases to receive satellite signals!
Package includes:
1 x Mini tracker
1 x cable
1 x Instructions
